Laravel 10 charts js example tutorial; In this Laravel 10 charts js tutorial will show you how to implement a pie chart using a chart js in Laravel 10 app.

ChartJS is simple, clean and engaging HTML5 based JavaScript charts. Chart.js is an easy way to include animated, interactive graphs on your website for free.

This charts js in Laravel 10 tutorial helps you step by step on how to fetch the last 7 days data and display it on laravel pie chart in laravel app using charts js.

Chart Js in Laravel 10 Example Tutorial

  • Step 1: Create a route
  • Step 2: Create Controller
  • Step 3: Create Blade View File and Integrate Chart js Library
  • Step 4: Start Development Server

Step 1: Create a route

In the first step, you need to create routes for the chart js. So go to routes/web.php and update the below route in your file:

<?php

use Illuminate\Support\Facades\Route;

use App\Http\Controllers\ChartJSController;

/*
|--------------------------------------------------------------------------
| Web Routes
|--------------------------------------------------------------------------
|
| Here is where you can register web routes for your application. These
| routes are loaded by the RouteServiceProvider within a group which
| contains the "web" middleware group. Now create something great!
|
*/

Route::get('chart-js', [ChartJSController::class, 'index']);

Step 2: Create Controller

Next step, you need to create a new controller name ChartController.php. And update the below code into your controller:

<?php

namespace App\Http\Controllers;

use App\Models\User;
use Illuminate\Http\Request;
use Redirect,Response;
Use DB;
use Carbon\Carbon;

class ChartJSController extends Controller
{
    /**
     * Display a listing of the resource.
     *
     * @return \Illuminate\Http\Response
     */
    public function index()
    {

 $record = User::select(\DB::raw("COUNT(*) as count"), \DB::raw("DAYNAME(created_at) as day_name"), \DB::raw("DAY(created_at) as day"))
    ->where('created_at', '>', Carbon::today()->subDay(6))
    ->groupBy('day_name','day')
    ->orderBy('day')
    ->get();

     $data = [];

     foreach($record as $row) {
        $data['label'][] = $row->day_name;
        $data['data'][] = (int) $row->count;
      }

    $data['chart_data'] = json_encode($data);
    return view('chart-js', $data);
    }

}

Step 3: Create Blade View File and Integrate Chart js Library

Final steps, in this step you need to create a blade view file. So go to the resources/views/chart-js.blade.php and update the below javascript and HTML code for displaying the pie chart using the chart js libraries:

<!DOCTYPE html>
<html>
<head>
  <title>Laravel 10 Chart JS Example Tutorial - Pie Chart - Tutsmake.com</title>
  <!-- Latest CSS -->
 <link rel="stylesheet" href="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/css/bootstrap.min.css">
 <script src="https://cdnjs.cloudflare.com/ajax/libs/Chart.js/2.8.0/Chart.js"></script>
 <script src="https://code.jquery.com/jquery-3.3.1.min.js"></script>
</head>
<body>
  <div class="chart-container">
    <div class="pie-chart-container">
      <canvas id="pie-chart"></canvas>
    </div>
  </div>

  <!-- javascript -->

   <script>
  $(function(){
      //get the pie chart canvas
      var cData = JSON.parse(`<?php echo $chart_data; ?>`);
      var ctx = $("#pie-chart");

      //pie chart data
      var data = {
        labels: cData.label,
        datasets: [
          {
            label: "Users Count",
            data: cData.data,
            backgroundColor: [
              "#DEB887",
              "#A9A9A9",
              "#DC143C",
              "#F4A460",
              "#2E8B57",
              "#1D7A46",
              "#CDA776",
            ],
            borderColor: [
              "#CDA776",
              "#989898",
              "#CB252B",
              "#E39371",
              "#1D7A46",
              "#F4A460",
              "#CDA776",
            ],
            borderWidth: [1, 1, 1, 1, 1,1,1]
          }
        ]
      };

      //options
      var options = {
        responsive: true,
        title: {
          display: true,
          position: "top",
          text: "Last Week Registered Users -  Day Wise Count",
          fontSize: 18,
          fontColor: "#111"
        },
        legend: {
          display: true,
          position: "bottom",
          labels: {
            fontColor: "#333",
            fontSize: 16
          }
        }
      };

      //create Pie Chart class object
      var chart1 = new Chart(ctx, {
        type: "pie",
        data: data,
        options: options
      });

  });
</script>
</body>
</html>

Note: Don’t forget to include the chart js libraries, jquery, and bootstrap CDN libraries on your blade view file and you can add or remove this library according to your requirement.

<link rel="stylesheet" href="https://stackpath.bootstrapcdn.com/bootstrap/4.3.1/css/bootstrap.min.css">
 <script src="https://cdnjs.cloudflare.com/ajax/libs/Chart.js/2.8.0/Chart.js"></script>
 <script src="https://code.jquery.com/jquery-3.3.1.min.js"></script>

Or also don’t forget to add this javascript code. The chart js library also provides so many options for the chart js. You can change or modify according to your requirements.

  <script>
  $(function(){
      //get the pie chart canvas
      var cData = JSON.parse(`<?php echo $chart_data; ?>`);
      var ctx = $("#pie-chart");

      //pie chart data
      var data = {
        labels: cData.label,
        datasets: [
          {
            label: "Users Count",
            data: cData.data,
            backgroundColor: [
              "#DEB887",
              "#A9A9A9",
              "#DC143C",
              "#F4A460",
              "#2E8B57",
              "#1D7A46",
              "#CDA776",
            ],
            borderColor: [
              "#CDA776",
              "#989898",
              "#CB252B",
              "#E39371",
              "#1D7A46",
              "#F4A460",
              "#CDA776",
            ],
            borderWidth: [1, 1, 1, 1, 1,1,1]
          }
        ]
      };

      //options
      var options = {
        responsive: true,
        title: {
          display: true,
          position: "top",
          text: "Last Week Registered Users -  Day Wise Count",
          fontSize: 18,
          fontColor: "#111"
        },
        legend: {
          display: true,
          position: "bottom",
          labels: {
            fontColor: "#333",
            fontSize: 16
          }
        }
      };

      //create Pie Chart class object
      var chart1 = new Chart(ctx, {
        type: "pie",
        data: data,
        options: options
      });

  });
</script>

Step 4: Start Development Server

Open terminal and execute the following command to start development server:

php artisan serve

Then open browser and fire the below given url on it:

http://127.0.0.1:8000/chart-js
